车载芯片

产品描述

• Linear topology

• Single host, multiple slaves

• The maximum distance between nodes is 15 meters, and the overall cable length reaches 80 meters

• Synchronize data

• Multichannel I2S/Time Division Multiplexing to I2S/TDM

• Low latency slave to slave communication

• I2C to I2C control and status information

• GPIO and interrupts

• Bus power or local power slave node



产品参数

• Power supply Voltage : 3.7-9.0[V]

• Transmission rate: 98Mbps

• Operation temperature range : -40 to 105[℃]

• 8-bit to 32-bit multi-channel I2S/TDM interface

• Programmable I2S/TDM data rate

• Up to 64 upstream and 64 downstream channels TDM/I2S interface

• Programmable PDM clock rate • Up to 4 high dynamic range microphone inputs

• Simultaneously receiving I2S data from up to 4 PDM microphones

• Provide a unique ID register for each transceiver

• Provide programmable settings to optimize EMC performance



产品规格

AEC-Q100                                                   Operation temperature range : -40℃ to 105℃
